Diaphragm valve
Material corp
PVC-U
Material etanșare
EPDM
Variante disponibile
7 dimensiuni DN
DKBOAV/CP NC — Pneumatically actuated diaphragm valve with monolithic flanged body, drilled ANSI B16.5 cl.150 #FF, Normally Closed
Pneumatically actuated diaphragm valve with monolithic flanged body, drilled ANSI B16.5 cl. 150 #FF. Normally Closed function
Informații Suplimentare
- Disponibil pe stoc sau la comandă
- Suport tehnic complet pentru instalare
- Certificat de conformitate inclus
- Livrare în toată România
Specificații (7 variante)
| Referință | DN | d | PN | L | Greutate | Material |
|---|---|---|---|---|---|---|
| DKBOAVNC012E | 15 | 1/2" | 6 | - | 875 g | PVC-U |
| DKBOAVNC034E | 20 | 3/4" | 6 | - | 955 g | PVC-U |
| DKBOAVNC100E | 25 | 1" | 6 | - | 1221 g | PVC-U |
| DKBOAVNC114E | 32 | 1" 1/4 | 6 | - | 1411 g | PVC-U |
| DKBOAVNC112E | 40 | 1" 1/2 | 6 | - | 3136 g | PVC-U |
| DKBOAVNC200E | 50 | 2" | 6 | - | 6351 g | PVC-U |
| DKBOAVNC212E | 65 | 2" 1/2 | 6 | - | 6952 g | PVC-U |
