Butterfly valve
Material corp
PVDF
Material etanșare
FKM code
Variante disponibile
17 dimensiuni DN
FKOF/FM — Butterfly valve with bare shaft
Butterfly valve with bare shaft
Caracteristici Tehnice
FK suitable for flanged JIS K10 wafer installation is also available on request in the size 10" (DN250), 14" (DN350) and 16" (DN400).
*ISO-DIN
**ANSI B.16.5 150
Note:EPDM, (d75-225) primary liner available
Informații Suplimentare
- Disponibil pe stoc sau la comandă
- Suport tehnic complet pentru instalare
- Certificat de conformitate inclus
- Livrare în toată România
Specificații (17 variante)
| Referință | DN | d | PN | L | Greutate | Material |
|---|---|---|---|---|---|---|
| FKOFFM050F | 40 | - | 16 | - | 674 g | PVDF |
| FKOFFM063F | 50 | - | 16 | - | 854 g | PVDF |
| FKOFFM075F | 65 | - | 10 | - | 1100 g | PVDF |
| FKOFFM090F | 80 | - | 10 | - | 1550 g | PVDF |
| FKOFFM110F | 100 | - | 10 | - | 1900 g | PVDF |
| FKOFFM140F | 125 | - | 10 | - | 2750 g | PVDF |
| FKOFFM160F | 150 | - | 10 | - | 3550 g | PVDF |
| FKOFFM225F | 200 | - | 10 | - | 6300 g | PVDF |
| FKOFFM280F | *250 | - | 10 | - | 13000 g | PVDF |
| FKOFFM280F | *250 | - | 10 | - | 13000 g | PVDF |
