Butterfly valve
Material corp
PVDF
Material etanșare
FKM code
Variante disponibile
10 dimensiuni DN
FKOF/FM LUG ANSI — Butterfly valve with bare shaft, version Lug ANSI
Butterfly valve with bare shaft, version Lug ANSI
Informații Suplimentare
- Disponibil pe stoc sau la comandă
- Suport tehnic complet pentru instalare
- Certificat de conformitate inclus
- Livrare în toată România
Specificații (10 variante)
| Referință | DN | d | PN | L | Greutate | Material |
|---|---|---|---|---|---|---|
| FKOALFFM112F | 40 | 1" 1/2 | 10 | - | 970 g | PVDF |
| FKOALFFM200F | 50 | 2" | 10 | - | 1250 g | PVDF |
| FKOALFFM212F | 65 | 2” 1/2 | 10 | - | 1500 g | PVDF |
| FKOALFFM300F | 80 | 3” | 10 | - | 2350 g | PVDF |
| FKOALFFM400F | 100 | 4” | 10 | - | 2700 g | PVDF |
| FKOALFFM500F | 125 | 5” | 10 | - | 4350 g | PVDF |
| FKOALFFM600F | 150 | 6” | 10 | - | 5150 g | PVDF |
| FKOALFFM800F | 200 | 8” | 10 | - | 7900 g | PVDF |
| FKOALFFM810F | 250 | 10” | 6 | - | 17800 g | PVDF |
| FKOALFFM812F | 300 | 12” | 6 | - | 25800 g | PVDF |
