M9.10 — Dual parameter analog signal monitor and transmitter
Dual Parameter Analog signal Monitor and Transmitter
Caracteristici Tehnice
MAIN CHARACTERISTICS
- Large graphic display
- Colour backlighting
- On-line help
- Simultaneous display of two parameters
- Free setting of the unit of measurement
- User-friendly calibration procedure
- In-line adjustment on actual sample
- Ability to manage active and passive analogue signals
- USB port for software upgrade
- Mechanical relay and solid state relay for external alarms and for the control of external devices
TECHNICAL DATA
General information - Compatible sensors:H Hall-effect flow sensors with frequency output, F6.60 electromagnetic flow sensors and all devices that generate a passive or active 4-20 mA signal
Materials: - Case: ABS - Display: PC - Panel and wall gasket: silicone rubber - 5-button keyboard: silicone rubber
Display: - LCD full graphic - Backlight version: 3 - colours - Backlighting activation: user adjustable with 5 levels of timing - Update rate: 1 second - Protection class: IP65 front
Frequency input range (frequency): 0÷1000Hz
Frequency accuracy (frequency): 0,5%
Analogue input range (current): 3.8÷21.0 mA
Analogue input accuracy (current): 0.01 mA
Electrical data - Supply voltage: from 12 to 24 VDC ±10% regulated - Max electrical consumption: < 300 mA
Environmental data - Operating temperature: from –10°C to 70°C (from 14°F to 158 °F) - Storage temperature: from -30°C to +80°C (from -22°F to +176°F) - Relative humidity: from 0 to 95% not condensing
Standards & Approvals - Manufactured under ISO 9001 - Manufactured under ISO 14001 - CE - RoHS Compliance - EAC
Informații Suplimentare
- Disponibil pe stoc sau la comandă
- Suport tehnic complet pentru instalare
- Certificat de conformitate inclus
- Livrare în toată România
Specificații (3 variante)
| Referință | DN | d | PN | L | Greutate | Material |
|---|---|---|---|---|---|---|
| M9.10.P1 | - | - | - | - | - | - |
| M9.10.W1 | - | - | - | - | - | - |
| M9.10.W2 | - | - | - | - | - | - |
