Solenoid valve
Variante disponibile
4 dimensiuni DN
"SP/NC" pilot solenoid valve — 3/2 way for direct assembly on actuator, NBR normally closed gaskets
3/2 way pilot solenoid valve, for direct assembly on actuator, with NBR** normally closed gaskets
Caracteristici Tehnice
Function:3/2 way; Rated diameter: 2.5 mm; Working pressure: 0÷ 10 bar; Flow rate: 200 l/min ( 6 bar Δp 1 bar); Voltage: 24V-110V-220V 40-60 Hz / 24V DC; Maximum absorption: 24 VA (AC), 8W (DC); Protection class: IP65; Air inlet: G1/8''; Cable inlet: PG9 ( 6÷9 mm); Temperature range: -10 °C ÷ +60 °C; Service: 100% ED; Weight: 290 g; Material: Body: aluminium/PBTB, Gaskets: NBR
Informații Suplimentare
- Disponibil pe stoc sau la comandă
- Suport tehnic complet pentru instalare
- Certificat de conformitate inclus
- Livrare în toată România
Specificații (4 variante)
| Referință | DN | d | PN | L | Greutate | Material |
|---|---|---|---|---|---|---|
| SPNC014N024DC | - | - | - | - | - | - |
| SPNC014N024AC | - | - | - | - | - | - |
| SPNC014N110AC | - | - | - | - | - | - |
| SPNC014N220AC | - | - | - | - | - | - |
