Ball valve
Material corp
PVC-U
Material etanșare
EPDM / FKM
Variante disponibile
7 dimensiuni DN
VKDIV/CE 90-240 V AC — DUAL BLOCK ball valve, female solvent-weld, metric, multi-volt electric actuator
DUAL BLOCK® ball valve with female ends for solvent welding, metric series with multi-volt electric actuator 90-240 V AC 50-60 Hz
Informații Suplimentare
- Disponibil pe stoc sau la comandă
- Suport tehnic complet pentru instalare
- Certificat de conformitate inclus
- Livrare în toată România
Specificații (7 variante)
| Referință | DN | d | PN | L | Greutate | Material |
|---|---|---|---|---|---|---|
| VKDIVEM016E / VKDIVEM016F | 10 | 16 | 16 | 14 | 1785 g | PVC-U |
| VKDIVEM020E / VKDIVEM020F | 15 | 20 | 16 | 16 | 1775 g | PVC-U |
| VKDIVEM025E / VKDIVEM025F | 20 | 25 | 16 | 19 | 1903 g | PVC-U |
| VKDIVEM032E / VKDIVEM032F | 25 | 32 | 16 | 22 | 2011 g | PVC-U |
| VKDIVEM040E / VKDIVEM040F | 32 | 40 | 16 | 26 | 2369 g | PVC-U |
| VKDIVEM050E / VKDIVEM050F | 40 | 50 | 16 | 31 | 2601 g | PVC-U |
| VKDIVEM063E / VKDIVEM063F | 50 | 63 | *10 | 38 | 3218 g | PVC-U |
