Ball valve
Material corp
PVDF
Material etanșare
FKM code
Variante disponibile
7 dimensiuni DN
VKDIF/SHX — DUAL BLOCK 2-way ball valve, handle lock + stainless inserts, female butt-weld
DUAL BLOCK® 2-way ball valve with handle lock and STAINLESS steel threaded inserts for fastening, with female ends for butt welding, metric series
Informații Suplimentare
- Disponibil pe stoc sau la comandă
- Suport tehnic complet pentru instalare
- Certificat de conformitate inclus
- Livrare în toată România
Specificații (7 variante)
| Referință | DN | d | PN | L | Greutate | Material |
|---|---|---|---|---|---|---|
| VKDIFSHX016F | 10 | 16 | 16 | - | 291 g | PVDF |
| VKDIFSHX020F | 15 | 20 | 16 | - | 272 g | PVDF |
| VKDIFSHX025F | 20 | 25 | 16 | - | 445 g | PVDF |
| VKDIFSHX032F | 25 | 32 | 16 | - | 584 g | PVDF |
| VKDIFSHX040F | 32 | 40 | 16 | - | 938 g | PVDF |
| VKDIFSHX050F | 40 | 50 | 16 | - | 1242 g | PVDF |
| VKDIFSHX063F | 50 | 63 | 16 | - | 2187 g | PVDF |
